Specifications
- Product name SQF 0.6-2N
- Product No 95027337
- Gross weight 12.6 kg
- Minimum borehole diameter 102 mm
Liquid
- Pumped liquid Water
- Maximum liquid temperature 40 °C
- Selected liquid temperature 20 °C
- Density 998.2 kg/m³
Electrical data
- Motor type MSF3N
- Power input – P1 1.4 kW
- Rated voltage ac 1 x 90-240 V
- Rated voltage dc 30-300 V
- Rated current 8.4 A
- Power factor 1.0
- Rated speed 3600 rpm
- Start. method direct-on-line
- Enclosure class (IEC 34-5) IP68
- Insulation class (IEC 85) F
- Motor protec Y
- Thermal protec internal
- Length of cable 2 m
Materials
- Pump Stainless steel
- Pump DIN W.-Nr. 1.4401
- Pump AISI 316
- Impeller Stainless steel
- Impeller DIN W.-Nr. 1.4401
- Impeller AISI 316
- Rotor DIN W.-Nr. 1.4401
- Rotor AISI 316
- Stator DIN W.-Nr. 1.4401
- Stator AISI 316
We want to help you
We have over 15+ years experience with the Grundfos SQFlex solar pump range. Let us give you an in-depth overview of how this pump will operate in your specific scenario.
The overview will give information on the following aspects of the system.
- Expected solar energy production for your area
- Solar energy required for the pump system to meet required water production
- Estimated water production per hour per day
- Recommendations for additional protection against the elements.
Some people learn from hard knocks and others learn from good advise. The choice is yours.
